资料名称Fairchild FAN9612双BCM BFC控制器方案
所在目录嵌入式解决方案
厂商
描述Fairchild 公司的FAN9612是隔行扫描的双临界工作模式(BCM) BFC控制器,采用并行连接的180度反相输出进行控制,控制功率从300W到800W.和连续导通模式(CCM)技术不同,BCM使得升压二极管在零电流开关,因此降低了成本和损耗.可应用于100-1000W离线电源,大屏幕LCD-TV,PDP-TV,RP-TV的电源以及高端台式计算机和服输器点名源,获得80+证书的设备.本文介绍了FAN9612的主要特性,方框图,典型应用电路图以及采用FAN9612隔行扫描的BCM PFC电路图. FAN9612: Interleaved Dual BCM PFC Controller The FAN9612 Interleaved Dual Boundary-Conduction-Mode (BCM) Power-Factor-Correction Controller operates two parallel-connected boost power trains 180º out of phase. Interleaving extends the maximum practical power level of the control technique from about 300W to greater than 800W. Unlike the continuous conduction mode (CCM) technique often used at higher power levels, BCM offers inherent zero-current switching of the boost diodes (no reverse-recovery losses), which permits the use of less expensive diodes without sacrificing efficiency. Furthermore, the input and output filters can be made smaller due to ripple current cancellation and effective doubling of the switching frequency. The converters operate with variable frequency which is a function of the load and the instantaneous input / output voltages. The switching frequency is limited between 18kHz ..
点击查看

资料相关产品

 页码:1/1
产品型号厂商封装简要描述图片资料订购
FAN3224TMXONSOP8MOS驱动 芯片ICFAN3224TMX
HFA15T60IRTO-220AC快恢复二极管LED电源 HFA15T60
HFA08T60IRTO-220ACON快恢复二极管LED电源 F20UP20DNHFA08T60
HFA08SD60SIRTO-252ON快恢复二极管LED电源 HFA08SD60SHFA08SD60S
FFA30U60DNONTO-3PON快恢复二极管LED电源 F30U60DNFFA30U60DN
FFA60UP20DNONTO-3PON快恢复二极管LED电源 F60UP20DNFFA60UP20DN
FFA60UP30DNONTO-3PON快恢复二极管LED电源 F60UP30DNFFA60UP30DN
FFA60UA60DNONTO-3PON快恢复二极管LED电源 F60UA60DNFFA60UA60DN
FFA40UP35SONTO-3PON快恢复二极管LED电源 F40UP35SFFA40UP35S
OPA551FAKTWTTITO-263-7高电流(380mA 典型值)、高电压 (60V) 运算放大器OPA551FAKTWT
OPA551FA/500TITO-263-7高电流(380mA 典型值)、高电压 (60V) 运算放大器OPA551FA/500
OPA552FAKTWTTITO-263-7高电流(380mA 典型值)、高电压 (60V)、高带宽 (12MHz) 运算放大器OPA552FAKTWT
OPA552FA/500TITO-263-7高电流(380mA 典型值)、高电压 (60V)、高带宽 (12MHz) 运算放大器OPA552FA/500
OPA452FAKTWTTITO-263-7运算放大器,单位增益稳定,带宽为 1.8MHzOPA452FAKTWT
OPA452FA/500TITO-263-7运算放大器,单位增益稳定,带宽为 1.8MHzOPA452FA/500
